Filters

Filters
The complete production programme of CleanAIR® canister filters offers a wide choice of filters for most industrial applications, pharmaceutical industry, laboratories and agriculture. The filters are supplied with a standard connection thread RD40×1/7" according to EN 148-1.

Particle filters

They catch a wide range of solid particles in the form of liquid and solid aerosols such as dust, smoke, fibres, bacteria, viruses and radioactive particles. Certification: EN 143, EN 12941, EN 12942
Gas filters
Provide protection against contaminants in the form of gases and vapours. EN 14387, EN 12941, EN 12942
Combined filters
Provide protection against a combination of contaminants in the form of gases, vapours and solid particles. EN 14387, EN 12941, EN 12942

Types of gas filters – general examples of application
Type: A
Areas of application: organic gases and vapours with a boiling point above 65 °C. The main group of these substances are hydrocarbons (e.g., toluene, benzene, xylene, styrene, cyclohexane, trichloroethylene, tetrachlormethan), organic solvents
and thinners (petrol, kerosene, diesel, mineral turpentine, ethylenglycol, methyl isobutyl ketone, isobuthanol, etc.).

Type: AX
Areas of application: organic gases and vapours with a boiling point below 65 °C. Substances with a low boiling point are, for example, acetone, acetaldehyde, acrylaldehyde, butane, butadiene, diethyl ether, dichloro ether, dichloromethane, ethylene oxide, methanol, trichloromethane, vinyl chloride.

Type: B
Areas of application: inorganic gases and vapours, e.g., fluorine, chlorine, hydrogen sulphide, hydrogen cyanide, hydrogen bromide, hydrogen chloride, hydrogen peroxide.

Type: E
Areas of application: acid gases and vapours (e.g., carbon dioxide, sulphuric acid, hydrochloric acid, formic acid, hydrogen fluoride).

Type: K
Areas of application: ammonia and organic amines
(e.g., methylamine, ethylamine, dimethylamine).

Type: Hg-PSL
Areas of application: Areas of application: mercury vapour and its compounds (always supplied in combination with a filter against particles P3).

PARTICLE FILTERS
Type: P3
Dimensions: diameter / height: 110 mm / 50 mm; Weight: 90 g
Product code: 50 00 48/6 , 50 00 48/60

Type: P3 lite
Dimensions: diameter / height: 110 mm / 50 mm; Weight: 86g
Product code: 50 40 48/6 , 50 40 48/50

Type: P3 ZERO lite with two threads RD40×1/7"
Dimensions: diameter / height: 110 mm / 65 mm; Weight: XX g
Connection: Inlet RD40×1/7", outlet RD40×1/7" (internal thread)
Areas of application: particles in the form of solid and liquid aerosols (dusts, fibres, toxic and non-toxic fumes, bacteria, viruses)
Product code: 50 42 49/5

Type: Filter P R SL, for CleanAIR Asbest
Dimensions: diameter / height: 110 mm / 57 mm; Weight: 101 g
Product code: 56 00 10/5 , 56 00 10/50

GAS FILTERS
Type: A2
Dimensions: diameter / height: 110 mm / 78 mm; Weight: 265 g
Areas of application: organic gases and vapours with a boiling point above 65 °C
Product code: 50 01 56/3

Type: B2
Dimensions: diameter / height: 110 mm / 78 mm; Weight: 400 g
Areas of application: inorganic gases and vapours
Product code: 50 01 61/3

Type: K2
Dimensions: diameter / height: 110 mm / 78 mm; Weight: 265 g
Areas of application: ammonia and organic amines
Product code: 50 01 59/3

Type: A2B2
Dimensions: diameter / height: 110 mm / 78 mm; Weight: 400 g
Areas of application: organic gases and vapours with a
boiling point above 65 °C and inorganic gases and vapours
Product code: 50 01 58/3

Type: A2B2E2
Dimensions: diameter / height: 110 mm / 78 mm; Weight: 400 g
Areas of application: organic gases and vapour with a boiling point above 65 °C, inorganic and acid gases and vapours
Product code: 50 01 63/3

Type: A2B2E2K2
Dimensions: diameter / height: 110 mm / 78 mm; Weight: 400 g
Areas of application: organic gases and vapours with a boiling point above 65 °C, inorganic gases and vapours, acid gases and vapours, ammonia and organic amines
Product code: 50 01 69/3

COMBINED FILTERS
Type: A2P3
Dimensions: diameter / height: 110 mm / 95 mm, Weight: 325 g
Areas of application: organic gases and vapours with a boiling point above 65 °C, particles
Product code: 50 01 57/3 , 50 01 57/30

Type: A1P3 – filter with low sorption capacity – class 1
Filter is not suitable against very high concentration of contaminants • Colour code:
Dimensions: diameter / height: 110 mm / 95 mm, Weight: 295 g
Areas of application: organic gases and vapours with a boiling point above 65 °C, particles
Product code: 50 03 57/3

Type: A3AXP3 – filter with high sorption capacity – class 3
Dimensions: diameter / height: 110 mm / 158 mm, Weight: 635 g
Areas of application: organic gases and vapours with a boiling point below 65 °C, particles
Product code: 50 01 70

Type: B2P3
Dimensions: diameter / height: 110 mm / 95 mm, Weight: 400 g
Areas of application: inorganic gases and vapours, particles
Product code: 50 01 62/3

Type: K2P3
Dimensions: diameter / height: 110 mm / 95 mm, Weight: 400 g
Areas of application: ammonia and organic amines, particles
Product code: 50 01 60/3

Type: A2B2P3
Dimensions: diameter / height: 110 mm / 95 mm, Weight: 425 g
Areas of application: organic gases and vapours with a boiling
point above 65 °C, inorganic gases and vapours, particles
Product code: 50 01 67/3

Type: A2B2E2P3
Dimensions: diameter / height: 110 mm / 95 mm, Weight: 400 g
Areas of application: organic gases and vapours
with a boiling point above 65 °C, inorganic gases and vapours, acid gases and vapours, particles
Product code: 50 01 64/3

Type: A1B1E1P3 – filter with low sorption capacity – class 1
Filter is not suitable against very high concentration of contaminants • Colour code:
Dimensions: diameter / height: 110 mm / 95 mm, Weight: 280 g
Areas of application: organic gases and vapours with a boiling point above 65 °C, inorganic gases and vapours, acid gases and vapours, particles
Product code: 50 03 64/3

Type: A2B2E2K2P3
Dimensions: diameter / height: 110 mm / 95 mm, Weight: 400 g
Areas of application: organic gases and vapours with a boiling point above 65 °C, inorganic gases and vapours, acid gases and vapours, ammonia and organic amines, particles
Product code: 50 01 68/3 , 50 01 68/30

Type: A2B2E2K2P3 ZERO, with two threads RD40x1/7″
Dimensions: diameter / height: 110 mm / 9111 mm, Weight: 410 g
Areas of application: organic gases and vapours with a boiling point above 65 °C, inorganic gases and vapours, acid gases and vapours, ammonia and organic amines, particles
Product code: 50 02 68/3

Type: A2B2E2K2HgP3
Dimensions: diameter / height: 110 mm / 95 mm, Weight: 425 g
Areas of application: organic gases and vapours
with a boiling point above 65 °C, inorganic gases and vapours, acid gases and vapours, ammonia and organic amines, mercury compounds and vapours, particles
Product code: 50 01 66/3

Type: NBC – A2B2E2K2P3, with two threads RD40x1/7″
Dimensions: diameter / height: 110 mm / 95 mm, Weight: 385 g
Areas of application: organic gases and vapours
with a boiling point above 65 °C, inorganic gases and vapours, acid gases and vapours, ammonia and organic amines, mercury compounds and vapours, particles
Product code: 50 02 65X/3

Type: NBC – A2B2E2K2P3
Dimensions: diameter / height: 110 mm / 95 mm, Weight: 380 g
Areas of application: organic gases and vapours
with a boiling point above 65 °C, inorganic gases and vapours, acid gases and vapours, ammonia and organic amines, mercury compounds and vapours, particles
Product code: 50 01 65X/3

Important notice: Canister filters are not compatible with PAPR units CleanAIR® AerGO® and CleanAIR® Basic
